Product details

Input voltage: AC100V-AC240V

Light source specification: LED 600W light source (including) or above

Light source lifespan: 20000 hours or more (inclusive)

Luminous illuminance: 113000 LUX at a distance of 5 meters

LED light source displays CRI: Ra>80, CRI filter Ra>90

Channel mode: 34CH

Horizontal/Vertical: 540 degrees/270 degrees (16 bit precision scanning) electronic error correction, equipped with photoelectric reset automatic error correction function

Dimming system: 0-100% linear adjustment

Atomization system: 1 independent atomization effect, soft and natural light spot.

Magnification angle: 7-42 degrees, zoom angle: 10-50 degrees (inclusive) or below.

High speed flicker: 0-30 times/second (inclusive) or above. Adjustable speed strobe effect.

Color: 5 colors+white light (inclusive) or above.

Color mixing system: Linear CMY color mixing+CTO linear color temperature system.

Fixed pattern: 6 or more fixed patterns (including)+white light+water pattern.

Rotating pattern: 7 or more glass patterns (inclusive), each glass pattern can be independently reversed.

Prism system: 4-prism, reversible.

Cutting disc: 8 motors can linearly cut various graphic effects+cutting rotation effect

Aperture effect: controllable spot size effect

Control modes: DMX512 mode, self-propelled mode, master-slave mode, voice control mode.

Display mode: LCD display, button+touch dual operation mode

Control signal: International standard DMX512, with RDM function.

The integration function with the existing stage lighting front-end installation must be normal.

Including hooks and seat belts. (Optional integrated light hook)

Warranty: Full machine warranty for 1 year or more (inclusive)

Protection level: IP20

Packaging size: 83x51X42cm

Net weight: 26KG

Gross weight: 31KG
